Heat Sink Customization
JY002
Technical requirements
1. Unnoted tolerances are in accordance with GB/T19314-92
2. Good molding, no distortion, flat surface, smooth, no scratches, no oil stains, no burrs on the cut edges
3. The flatness of the solder pin and component assembly surface is ≤0.05mm, and the roughness is ≤3.2μm
4. The resistance value between the solder pin and the radiator body is ≤2.0 ohms
5. The riveting tension between the solder pin and the body is greater than 39.2N
6. No rust after 24 hours of salt spray test
7. The screw thread can withstand a minimum torque of 5KG and will not slip
8. This product must comply with the requirements of RoHS and REACH directives
